Diamond Cutter Wheels
KDS 50HD Diamond Cutter Wheel

When used with EX patch planers, it is possible to mill longitudinally in front of the excavator as well as 90° across the excavator without having to move the excavator. You can even work to the side of the excavator. DMW, EK or KTR attachments working in combination with KRM rotation units can also benefit from this flexibility of working position. Horizontal slots can be cut easily using a KDS attachment together with a KRM rotation unit.
Depending on the application, productivity can be increased by up to 50 percent when using KRM rotation units – especially in sewer and pipeline construction, profiling and tunnelling.
-
Recommended excavator weight40,000 – 66,000 lb
-
Rated power208 hp (230 kW)
-
Max. saw blade diameter (A)71 in
-
Max. torque at 350 bar1,130 lbf·ft
-
Max. rotation speed1,700 rpm
-
Max. oil flow124 gal/min
-
Max. operating hydraulic pressure5,000 psi (350 bar)
-
Weight of drive unit excl. saw blade and protective cover1,875 lb
